China Floating Ball Valve
UTMOST, a floating ball valve factory, floating ball valve supplier, floating ball valve manufacturer, offers different floating ball valve types at a good float ball price. The floating ball valve has a simple structure and good sealing performance, but the load of the working medium on the sphere is all transmitted to the outlet sealing ring. Therefore, it is necessary to consider whether the sealing ring material can withstand the working load of the sphere medium. When subjected to higher pressure impact, the sphere may shift. This valves and controls structure is generally used for medium and low-pressure ball valve and float.

Floating Ball Valve Application of Norms
Flange dimensions to ANSI B 16.5

Face to face dimensions to ANSI B 16.10

Floating ball valve design and Manufacture in accordance with API 6D

Valve tested to API 598

Floating Ball Valve Datas

Materials of Water Tank Ball Float Main Parts
No. Parts Name Material
Stainless Steel Cast Steel
1 Body A351 CF8 A216WCB
2 Stud A193 B8 A193 B7
3 nut A1942H A1942H
4 Gasket PTFE PTFE
5 Valve cover A351 CF8 A216WCB
6 Ball A182 F304 A182 F304
7 Seat PTFE PTFE
8 Stem A182 F6 A182 F6a
9 packing PTFE PTFE
10 Gland A182 F304 WCB
11 Handle A351 CF8 A216WCB

Main Performance Specification of SS Ball Float Valve
Performance Specification Pressure Grade (class)
150 300 400 600
Testing Pressure (Mpa) Shell test 2.93 7.58 10 15
Seal test 2.07 5.52 7.31 11.03
Air test 0.6Mpa
Applicable Temperature - 196Ps550°c (Different Materials for Different Operating Temperatures)
Applicable Medium Ordinary type Water, Steam, Petroleum, LPG, Natural gas, etc.
Antisulphur type Natural gas containing H2S and CO, petroleum, etc

Now the floating ball valve price is reasonable, anything you need, please contact us.

As a valve factory, we will do our best to meet all the needs of customers.
