1-PORT 1000M FX + 1-PORT 1000M TX MEDIA CONVERTER
Fibridge F6-1GT1GX series network management switch is a high-performance ethernet access equipment developed by Beijing Fibridge. It has 1 10/100/1000 mbps Ethernet interfaces and a 1000 mbps optical port. The device is built-in power module, you can choose 220V AC input or 12V DC input products. The F6 series is compact desktop design, small size, light weight, easy to place on desktop or in cabinet.

Specification of 1-Port 1000M Fx + 1-Port 1000M Tx Media Converter Switch
NETWORK CHARACTERISTICS
ETHERNET PROTOCOL Support IEEE802.3/802.3u/802.3x/802.3az
FLOW CONTROL IEEE802.3x flow control
NETWORK INTERFACE OPT: 1000MBase-FX Single/multimode SC/FC/SFP/1*9
ETH: 10/100/1000MBase-T(X)Adaptive Ethernet RJ45 port
VLAN No
MAC ADDRESSES 1K
HUGE FRAME No
CACHE NO
PACKET BUFFER 4Gbps
PACKET FORWARDING RATE 2.896Mpps
MANAGEMENT No
OPTICAL CHARACTERISTICS
OPTICAL INTERFACE SC/FC/SFP/1*9(Optional)
FIBER CORE COUNT Single / Dual core transmission
WAVELENGTH 1310nm/1550nm（850nm）
FIBER MODE Single Mode / Multimode
ENVIRONMENTAL CHARACTERISTICS
TEMPERATURE & HUMIDITY Working temperature: -10℃～50℃
Storage temperature: -40℃～75℃
Working humidity: 10%～90% RH No condensation
Storage humidity: 5%～90% RH No condensation
POWER AC 100-240V/50-60Hz Built-in switching power supply,
DC12V 1A External power supply
MTBF ≥100000 hours

Features of 1-Port 1000M Fx + 1-Port 1000M Tx Media Converter
Support IEEE802.3/802.3u/802.3x/802.3az forward mode.

Support for Port auto-negotiation.

Support flow control.

Industrial & Modular design make the equipment reliable and flexible.

Support overload protection.

Anti-link protection is supported.

Support light hot plug.

ISO9000 quality system certified.

Pass the ministry of public security testing.

Obtain network qualification certificate.

As one of industrial ethernet switch suppliers, we will do our best to meet all the needs of customers.
