Charging Pin Connector For GB/T EV Charging Plug
AP GB/T AC terminals are suitable for GB/T standard charging plugs and sockets to the GB/T 20234.2-2015 requirements. It owns soft and stable mating forces and the material of contact parts mainly adopts beryllium bronze with silver or gold coating for plating technology.

Features of AC/DC Terminal Pins and Connectors

Mechanical life ≧10000 times

Flexible custom design to realize high current and special structure

High ampacity, low-temperature rise

Safe installation and connecting

Anti-shock and durability design

Material of AC/DC Charging Pin Connector Terminal Pins
（1）Material: Brass, Copper

（2）Contact Material: Beryllium bronze

（3）Plating Material: Gold, Silver

Tips: Customized according to customer requirements

Specifications of Charging Pin Connector AC/DC Terminal Pins
DC GB/T Terminal
Item dimension（mm） Rated current and function

LN terminal 12 250A/200A/125A/80A

PE terminal 6 earthing
cc1 terminal 3 signal
cc2 terminal 3 signal

AC GB/T Terminal
Item dimension（mm） Rated current and function

LN terminal 6 200A/32A/16A
PE terminal 6 63A/32A/16A
CC terminal 3 signal
