CUPVC H05V-K single-core flex cable is named according to harmonized standard. In British, the H05V K cable/wire refer to 2491X. H05V K wire features flex copper conductor class 5 and PVC insulation with voltage 300/500V.
H05V-K cable is designed to use in the switch control, relay and internal connection or power switchgear as internal equipment wire. It is normally laid up in conduits, trunking or in the open air.
We supply the H05V-K cables according to BS EN 50525-2-31. The color of insulation can be customized as your requirements.

CUPVC H05V-K Single Core Flex Cable Characteristics
Normal size conductor diameter Average insulation thickness External diameter Max resistance at 20 Approx cable weigh
coresxmm2 mm mm mm Ω/km kg/km
1x0.5 0.9 0.6 2.5 39 9
1x0.75 1.1 0.6 2.7 26 11
1x1 1.3 0.6 2.8 19.5 14

Description Of CUPVC H05V-K Single Core Flex Cable
Conductor: plain annealed copper class 5, flexible
Insulation: PVC, TI1 quality
Colour: H05V-K: white, yellow, green black, orange, pink, red, blue, brown, grey, orange, pink, red, light blue, violet, green/yellow.
Standard: BS EN 50525-2-31
Voltage: 300/500v
H07V-K: black, blue, brown, grey, orange.
Application Of CUPVC H05V-K Single Core Flex Cable
H05V-K: widely used in the ground above or fixed in pipes only if used for signaling or control circuits. Not allowed to be used in water.
H07V-K: widely used in the ground above or fixed in pipes or in similar closed systems. The cable is a good option to protected installation in lighting and control appliances for voltage up to 1000V in c.a. or up to 750 V in c.c. landward. Not allowed to be used in water.

As one of copper wire manufacturers in china, we will do our best to meet all the needs of customers.
