[a]https%3A%2F%2Fwww.cn-jkz.com%2Finduction-heating-frequency-selection.html[/a] <br> <br>#induction #frequency <br> <br>Why we need to consider the induction heating machine output frequency when we adopt induction frequency heating method to heat the workpiece? <br>What is the relation between the workpiece size, application with the frequency? <br>The induction heating power supply is an industrial application that heats the workpiece by high frequency induction hardening. The higher the frequency of the current passed in the output coil, the less the penetration depth of the induced current generated on the surface of the heated body. The skin effect is more obvious. According to the calculation of the penetration depth of the induced current and the actual application, we give the following reference frequency selection: <br> <br>Surface Heating (such as hardening) <br>Hardening depth 0.8-1.2mm, the heating machine frequency should be at the range of 200-400KHZ <br>Hardening depth 1-2mm, the heating machine frequency should be at the range of 60-200KHZ <br>Hardening depth 2-4mm, the heating machine frequency should be at the range of 15-30KHZ <br>As one of the professional induction hardening machine manufacturers in China, JKZ strongly recommends you to select the frequency range in accordance with the needs of your workpieces.  <br> <br>Whole Piece Heating (such as induction forging application) <br>Workpiece diameter 20-30mm, the induction heater frequency should at the range of 15-30KHZ <br>Workpiece diameter 30-50mm, the induction heater frequency should at the range of 6-15KHZ <br>Workpiece diameter 50-80mm, the induction heater frequency should at the range of 2-5KHZ <br>Workpiece diameter above 80mm, the induction heater frequency should within 2KHZ <br> <br>Induction Melting <br>According to the metal material and melting capacity, the induction melting machine frequency should choose 3-30KHZ <br> <br>Induction Brazing <br>According to the brazing material, welding depth, workpiece thickness, the induction brazing frequency range should be 15-300KHZ <br> <br>If you are looking for a reliable induction heating company, don&#039;t hesitate to contact us!

[a]https%3A%2F%2Fwww.cn-jkz.com%2Finduction-hardening-heating-machines.html[/a] <br> <br>#induction #hardening #machine <br> <br>The induction hardening process is a very important way in the manufacturing process of heat treatment of mechanical parts. In order to improve the hardness of metal&#039;s surface, not only should the surface layer depth of the workpiece reach the industrial design standard, but the heat treatment production plants are also needed to introduce the hardening process in the production. Functioning as an effective tool to implement the induction hardening process of steel, the induction hardening machine occupies an irreplaceable position in many heating methods, especially in the control of layer depth and temperature control. As a mature induction hardening machine manufacturers, JKZ sells 1-10KHZ medium frequency induction furnaces, 15-30KHZ ultrasonic frequency induction heaters, 30-60KHZ high-frequency induction heating machines, and 50-120KHZ super high-frequency small induction heating machines of high quality. These induction hardening machine hold the power range from 7.5KW to 600KW, which can process workpieces with a diameter up to 2000mm and hardening depth from 1 to 20mm. Moreover, capable of working together with CNC/PLC hardening machine scanner system, JKZ&#039;s Induction heating equipment can also accurately control the induction heating coil moving speed, workpiece rotation speed, power output percentage, layer depth, and quenching liquid spray time. Thus, if you are still looking for a tool to conduct effective application of induction surface hardening, our industrial heating unit can then perfectly meet all your needs for the hardening and heating processes. <br> <br>Induction Hardening VS Case Hardening <br>Comparing the two methods of quenching steel workpieces, the first significant difference is part handling. Surface hardening can process a large number of workpieces at the same time, while induction hardening focuses on a single workpiece. Through induction hardening, the parts are quenched one by one. <br>Case hardening relies on parts logistics to transport parts between the production line and hardening. Induction hardening can be directly integrated into the production line as part of the cycle with a suitable hardening machine. <br>Case hardening in detail <br>As mentioned above, surface hardening is carried out in batches. As with induction hardening, the goal is to harden the outer layer of the workpiece. <br>In the case of quenching, the workpiece is hardened by carburizing. The steel is heated above 880°C to become austenite. The coal is then transferred from the CO emission medium to the part through the surface of the part. Diffusion causes the edges of the workpiece to receive more carbon, while the carbon density in the center remains the same. <br>There are two ways to influence the depth of hardening in surface hardening: one is to manipulate the heating of the workpiece, for example, by using a special paste to prevent certain places from being heated. The other is by influencing the quenching process, for example by immersing only certain parts of the workpiece. <br>Using these two methods, the results are not particularly accurate, and can only be reproduced within a relatively wide tolerance range. This is very different from induction hardening. <br>Induction hardening in detail <br>As mentioned above, each part is individually quenched using induction hardening technology. Each part is heat treated, quenched and annealed separately. In addition to being integrated into the production line, the great advantage of induction hardening is the precise control and reproducibility of the quenching results. In order to achieve this, the entire hardening process from the inductor and the applied energy and frequency to quenching and annealing has been specifically adjusted for the relevant workpiece. Even for workpieces with complex geometries, this can produce excellent quenching results.

[a]https%3A%2F%2Fwww.cn-jkz.com%2Finduction-annealing-and-normalizing-heating-machines.html[/a] <br> <br>#Induction #annealing <br> <br>Induction annealing and induction tempering are very important processes in the heat treatment of the metal workpiece. These two processes can effectively change the hardness of the processed metal materials so as to meet different industry production requests. In the situations like steel wire annealing, spring wires annealing, tube annealing, shafts surface heating, gear teeth hardening, and sleeves inner bore heating, you can all find the existence of induction/annealing wire with induction machines. Through annealing/tempering induction heat treatment, the performance of the workpiece can be much improved according to the customer&#039;s technical requirements to meet the induction annealing process requirements of the workpiece. As a professional induction brass annealing machine manufacturer in China, JKZ can provide you with both MOSFET and IGBT inverter types induction annealing machines with a frequency range from 1KHz to 120KHz. We also sell single wire annealing machines with the power range of 7.5KW to 600KW in case you need to deal with the heating of workpieces of different shapes and different materials. For instance, with our wire annealing machines, you can easily process metals like carbon steel, stainless steel, copper, brass materials, titanium, metal parts like automotive parts, shafts, gears, sprockets, etc. Aiming to meet the requirements of various remote control PLCs and temperature control systems, JKZ&#039;s induction annealing machine can perfectly meet our customers&#039; heating requirements to the greatest extent. <br> <br>If you are looking for a reliable induction heater factory, don&#039;t hesitate to contact us!

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fmfs-160a-medium-frequency-induction-heating-machine.html[/a] <br>#induction #heating #furnace <br>MFS-160A medium frequency induction heating machine inverter uses IGBT as the core component. The heating furnace frequency is designed according to the size of the workpiece, ranging from 1KHZ to 10KHZ. As a member of the MFS series, MFS-160A&#039;s single set maximum power can reach 600KW, and it uses standard voltage 3 Phases 380V/50HZ. Special voltage standard for this device is also available for further customized design. <br> <br>The applications of this medium frequency induction furnace are billets forging heating such as auto parts production and heat treatment surface hardening like the shafts, gears, metal melting furnace, tube bending, and elbow making. <br> <br>Adopting touch screens with the embedded program, MFS-160A can also reduce the difficulty of the operation. <br> <br>JKZ also provides vertical and horizontal designs according to the customers&#039; installation situations. <br> <br>Application of MFS-160A Medium Frequency Induction Heating Machine <br> <br>Forging: suitable for forging of steel, stainless steel, copper and aluminum of Ø40mm-Ø60mm <br> <br>Hardening: suitable for hardening depth of 5-10 mm of Ø60-Ø160mm steel bar <br> <br>Melting: suitable for smelting 100-160 kg of non-ferrous metals <br> <br>For more information about china induction heating furnace and induction heating system, please feel free to contact us!

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fmfs-120a-medium-frequency-induction-heating-machine.html[/a] <br>#Induction #Heating #Machine <br>MFS 120 A induction heating power supply adopts IGBT as the core component. As a medium frequency induction heating machine, MFS-120A has an output frequency ranging from 1KHZ to10KHz, and the single machine power is up to 600kw (3Phases~380v). <br> <br>It is suitable for billets hot forging heating, induction heat treatment and other application fields of slightly larger workpieces. It adopts a fully digital control circuit. <br> <br>HMI adopts touch screen to reduce the difficulty of the operation and provides vertical or horizontal design according to the customer&#039;s on-site space to facilitate customer&#039;s on-site installation and operation. <br> <br>Application of MFS-120A Medium Frequency Induction Heating Machine <br> <br>Forging: suitable for forging of steel, stainless steel, copper and aluminum Ø40mm-Ø60mm <br> <br>Hardening: suitable for hardening depth of 5-10 mm of Ø60-Ø160mm steel bar <br> <br>Melting: suitable for smelting 100-160 kg of non-ferrous metals <br> <br>For more information about china induction melting, please feel free to contact us!

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fmedium-frequency-induction-heating-machine%2F[/a] <br>#induction #heater <br>If you need hot forging for large workpieces, smelting for ferrous or non-ferrous metals or deep heat treatment, the MFS series of intermediate frequency induction heating equipment is your most correct choice. <br>Advantages of medium frequency induction heating equipment <br> <br>The induction heating speed is fast and the temperature uniform is good. The MFS series induction heating power supply can design the operating frequency according to the actual needs of customers. The workpiece is non-contact heating. The metal workpiece heats itself through the alternating eddy current, which has high efficiency and a good temperature uniform effect. <br> <br>The induction heating energy efficiency is high. As a mature medium frequency induction heating series, the MFS series adopts IGBT and adjusts the power by adjusting the wave, and uses high-quality copper material as the main circuit base layer, which can effectively reduce the loss of the components and the circuit itself. <br> <br>The design of this medium frequency induction heating machine can also allow customers to directly set the working status (power, working mode, etc.) of the heating equipment through the touch screen. At the same time, customers can also accept external PLC control through RS485 or reserved external signal I/O modules. <br> <br>Standard MFS can be applied to wide voltage fluctuation (*360V~440V), and non-standard voltage power supply can also be customized according to the actual situation of customers. <br> <br>This medium frequency induction furnace is also equipped with a condition monitoring system(CMS) and a built-in condition detection system just like any other induction heating system launched by JKZ. Through the single-chip microcomputer, this medium frequencty induction heating series can effectively monitor the temperature, current, voltage, water flow, etc. of the main components of the equipment. Problems like overvoltage, undervoltage, overtemperature, water shortage, phase failure, and overcurrent can be easily detected. <br> <br>With different output modules, MFS series induction heating power supplies can complete induction forging, induction quenching, and non-ferrous metal induction smelting. <br> <br>JKZ, as an excellent induction heater manufacturer, offers a wide range of induction heating device for you to choose from.

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fhigh-frequency-induction-heating-machine%2F[/a] <br>#induction #heating <br>The working frequency of CX series ultra high frequency induction heating machine covers 50KHZ ~ 120KHZ. You can find the existence of this high frequency heating machine series in induction welding, tool welding, pipe welding, thermal nesting, thermal packaging, etc. <br> <br>Types of High Frequency Induction Heating Machine for sale <br>The high-frequency induction heating equipment is used for various industrial applications such as metal hardening, brazing, welding, forging, and heat treatment. These machines are available in different types and configurations to suit specific heating requirements. Here are some common types of high-frequency heating machine for sale that you can learn detail: <br> <br>Advantages of JKZ high frequency induction heating machine <br>Strict selection of high-quality components and optimized design scheme. After long-term use, the induction generator of JKZ high frequency induction heating equipment can still work stably and reliably. <br> <br>A variety of remote control schemes can be selected, and this induction heating equipment can also allow you to control the working status of your high-frequency induction heating equipment through various signals such as on-off signals, 4-20mA, 0-10V, etc. <br> <br>Equipped with a condition monitoring system (CMS), JKZ high power induction heater can alarm its users about possible equipment failures in real-time <br> <br>With a lightweight design scheme, it is convenient for customers to flexibly adjust the installation location of our high-frequency inverter for induction heating. <br> <br>The induction coil of our high-frequency induction heating machine is simple to make and can be adapted to various workpieces of different shapes. <br> <br>Principle of high frequency induction heatingg <br>The induction coil of the high-frequency induction heater will generate a powerful magnetic beam of polar instantaneous changes. When operating a high-frequency heater, the metal that requires heat treatment will be placed in the high-frequency coil, and the magnetic beam mentioned above will penetrate the entire ready-to-be-heated metal object. The corresponding powerful high-frequency eddy current heating will then be generated. Since there is a resistor in the metal, strong jeophenia will then be generated and cause the temperature of the inductive heating material to rise rapidly, thereby achieving high-frequency heat treatment. <br> <br>High Frequency Induction Heating Is Used For？ <br>The main applicable industry range of the high-frequency induction heating machine mainly includes high-frequency wave induction, high-frequency sensing heat treatment, high-tech wave induction metal smelting, etc. <br> <br>High-frequency induction heating generator is a process that uses an electromagnetic field to generate heat in a metal object. It is used in various industrial applications, including: <br> <br>Brazing and soldering: Induction heating is used to join two metal parts by melting a solder material between them. <br> <br>Heat treatment: Induction heating can be used to harden, soften, or temper metals, improving their mechanical properties. <br> <br>Melting and casting: High-frequency induction furnace can melt and cast metals, such as steel, copper, and aluminum. <br> <br>Welding: HF induction welding is a non-contact method of joining two metal parts by heating them to a temperature where they fuse together. <br> <br>Annealing: Induction annealing is a process that heats a metal to a specific temperature and then cools it slowly, making it more ductile and easier to work with. <br> <br>Surface hardening: high frequency heat treatment can be used to selectively harden the surface of a metal object, making it more wear-resistant. <br> <br>Shrink fitting: High-frequency induction heating can be used to expand a metal object and then quickly cool it, causing it to contract and fit tightly onto another part. <br> <br>JKZ, as an excellent induction heating manufacturer, offers a wide range of induction heating inverter for you to choose from.

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fcx2030c-high-frequency-induction-heating-machine.html[/a] <br>#heating #machine <br>CX2030C 50-120KHZ high-frequency MOSFET type induction heater holds the output power of 15KW/30KVA. It is suitable for soldering, welding and quenching heating of small metal parts. Produced by a famous brand, MOSFET of our high frequency induction heater is quality reliable. With rich experience in producing induction heating units, JKZ has also equipped CX2030C with a mature design so as to ensure stable equipment performance. Having the functions of remote start/stop, CX2030C also has a remote power control system that can be designed according to customers&#039; actual requirements. Thus, it is easy to combine the machine to work together with the production line. <br> <br>Induction hardening machine specification <br>CX2030C 30 kva induction heater is a specialized industrial device used for heating and treating various materials through electromagnetic induction. The high-frequency 30kw induction heater machine operates on the principle of electromagnetic induction, where alternating current (AC) passes through a coil (inductor), creating a rapidly changing magnetic field. This magnetic field induces eddy currents within the electrically conductive workpiece placed within or near the coil, causing it to heat up. <br> <br>Advantage of CX2030C 30KW Induction Heater <br>Our 30 kw induction heater offers several advantages for various industrial heating and processing applications. Here are some of the key advantages: <br> <br>1. Precision Heating: Induction heaters provide precise control over the heating process. The power output can be adjusted to achieve the desired temperature and heating rate, making it suitable for applications requiring precise temperature control. <br> <br>2. Efficiency: Induction heating is highly efficient because it directly heats the workpiece or material, minimizing heat loss to the surroundings. The CX2030C 30 KVA induction heater can provide rapid and uniform heating, ensuring energy is used efficiently. <br> <br>3. Versatility: A 30kw induction heater can be used for a wide range of applications, including brazing, welding, hardening, annealing, forging, and more. It can handle different materials, sizes, and shapes of workpieces. <br> <br>4. Cost Savings: Efficient heating and precise control can lead to cost savings in terms of energy consumption, reduced scrap rates, and improved overall process efficiency. <br> <br> <br>Application of CX2030C High Frequency Induction Heating Machine <br>The CX2030C 30KW induction heater has a versatile range of applications, as indicated by the provided points: <br> <br>1. Brazing of length 6~40mm carbide and other materials <br>This machine can be used for brazing operations, which involve joining different materials, such as carbide, with lengths ranging from 6 to 40mm. Brazing typically requires precise and controlled heating to melt a filler material and create strong joints. <br> <br>2. Welding of Ø6~15mm copper pipe <br>Induction welding of the 30 KW induction heater offers a fast and efficient method for joining copper pipes, ensuring reliable connections. <br> <br>3. Non-ferrous metal smelting <br>Smelting involves melting raw materials to extract the desired metal, and induction heating can provide the necessary high temperatures for this process. <br> <br>4. Forging heating of Ø8-10mm steel rod <br>Forging heating is a crucial step in shaping steel rods. The CX2030C 30 kva induction heater can efficiently heat steel rods with diameters of 8 to 10mm, making it suitable for various forging applications, including blacksmithing and industrial forging. <br> <br>5. Hardening of small workpiece whole piece or surface layer. <br>Hardening involves heating the material and then rapidly cooling it to increase its hardness and wear resistance. <br> <br>JKZ, as an excellent heating machine manufacturer, offers a wide range of induction heating inverter for you to choose from.

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2Fcx2020a-high-frequency-induction-heating-machine.html[/a] <br>#induction #heating #equipment <br>CX2020A high-frequency induction forging machine is designed to work at the frequency range of 50~120KHz and its output power range is 10KW. It is often used for induction brazing, welding, small parts forging heating and heat treatment. The core component of this high power induction heater is MOSFET, which is adapted from a well-known manufacturer. Its mature and stable circuits design ensure reliable equipment performance. With the remote control modules for start/stop, remote power adjustment can also be customized according to customer requirements, and this design makes it simple to embed this equipment into automated production lines. <br> <br>Specifications of CX2020A High Frequency Induction Heating Machine <br>Our 20KW High-Frequency Induction Hardening Machine represents a cutting-edge heating method tailored for industrial applications. In numerous modern manufacturing processes, this heat-frequency machine provides an appealing blend of speed, uniformity, and precision control. <br> <br>Operating on the principle of magnetic field induction, this high-frequency metal hardening furnace finds broad utility and is adaptable to a wide range of metal workpieces, regardless of their size or shape. The primary applications of the 20kw induction heater encompass tasks such as melting, annealing, quenching, welding, heating, and various other heat treatment procedures. The following is the induction hardening machine specification CX2020A: <br>Input voltage 1 Phase 220V±10%  50/60HZ <br>Input AC current 45A <br>Output power 20KVA <br>Output frequency 50-120KHZ <br>Duty cycle 100% <br>Power factor ≥95% <br>Cooling water pressure 0.1-0.15 MPa <br>Cooling water flow ≥0.7 m³/Hour <br>Features of CX2020A High-Frequency Induction Quenching Machine <br>The CX2020A high frequency induction machine has a rapid and highly efficient heating process. <br> <br>Precise heating targeting specific areas, resulting in minimal distortion. <br> <br>Swift heating cycles with a clean, oxide-free workpiece surface. <br> <br>The high-frequency induction welder has a user-friendly operation, promotes a favorable working environment, and minimizes environmental impact. <br> <br>Easily adjustable heating temperature and duration control, ensuring consistent heating quality and enabling streamlined production processes. <br> <br>Advantages of 20KW Induction Heater <br>Purpose of Heat Treatment: Induction hardening of heat-frequency machine is used to modify the characteristics of metal materials, enhancing mechanical properties like strength, hardness, plasticity, toughness, and fatigue strength. The process involves preliminary and final heat treatments. Preliminary treatments adjust material properties, such as normalizing low-carbon steel for increased hardness or spheroidizing high-carbon steel for reduced hardness. Final heat treatment achieves the desired mechanical properties by quenching and tempering. <br> <br>Maintenance and Troubleshooting: Issues in the induction heating equipment may result from low insulation resistance or furnace short-circuits. To address this, a megohmmeter is employed to detect furnace resistance and eliminate short-circuits. If resistance is excessively low, rebuilding the furnace may be necessary. <br> <br>Advantages of CX2020A high-frequency induction welder: This method offers deeper and harder layers with superior wear resistance compared to laser hardening. However, it can affect workpiece surface roughness, often necessitating additional machining to restore smoothness. The high-frequency induction quenching machine can produce a specialized laser melting and quenching coating, effectively reducing surface roughness in the fusion layer. <br> <br>Application of CX2020A heat frequency machine <br>Brazing of length 6~40mm carbide and other materials <br>Welding of Ø6~15mm copper pipe <br>Non-ferrous metal smelting <br>Forging heating of Ø8-10mm steel rod <br>Hardening of small workpiece whole piece or surface layer. <br> <br>JKZ, as an excellent induction heating machine manufacturer, offers a wide range of induction heating equipment for you to choose from.

[a]https%3A%2F%2Fwww.cn-jkz.com%2Fproducts%2F[/a] <br>#Heating #Machine <br>JKZ Induction Heating has been engaged in the manufacturing of induction heating machines for nearly 30 years. At present, there are currently more than 10,000 JKZ induction heater machine working all over the world. Based on the principles of induction technological updates and customers&#039; needs, JKZ Induction Heating has always been striving to produce industrial induction heating machines with JKZ Induction Heating&#039;s own characteristics and independent core technologies in the induction heating industry. With the upgrading of induction heating equipment from generation to generation, as well as our rich experience in induction heating industrial applications, we serve end customers with high-quality industrial induction heating machine all over the world. Taking &quot;win-win with customers&quot; as our value foundation, JKZ Induction Heating, with our complete R&amp;D designs, project solutions, production team, and after-sales support, are looking forward to cooperating with you. <br> <br>Compare different types of induction heating equipment <br> <br>Different Frequencies <br>Induction tempering machine with a frequency of 1-10Khz is usually regarded as medium-frequency induction heating equipment, and induction heating equipment with a frequency above 50Khz as high-frequency induction heating equipment. <br> <br>Different Quenching Depth <br>Affected by the frequency of heat induction machine, the quenching depth of the two is also different. The quenching depth of medium frequency induction heating equipment is generally 3.5-6mm, while that of high frequency induction heating equipment is 1.2-1.5mm. <br> <br>Different Diathermy Diameters <br>Medium frequency induction heating equipment has great advantages in the diathermy of workpieces. It is mainly used for diathermic heat treatment of workpieces. It can perform diathermic heat treatment on workpieces with a diameter of 45-90mm. However, high-frequency induction heating equipment can only dilute the thin and small workpieces. <br> <br>Induction Heating VS Other Heating Methods <br>Induction heating is different from some common heating methods in that it does not rely on convection and radiation to transfer heat to the surface of the product. Instead, the surface of the product generates heat through current, and then the heat from the surface of the product is transferred to the product through heat conduction. The depth of direct heating using induction current depends on the electrical reference depth. <br> <br>Unlike some combustion methods, induction heating can be precisely controlled regardless of batch size. By changing the current, voltage and frequency of the induction coil, fine-tuned engineering heating can be achieved, which is very suitable for precision applications such as surface quenching, quenching and tempering, and annealing. The precise heating control provided by induction is unparalleled. In addition, using the same heating principle as the vacuum crucible heating application, induction heating can be carried out in the atmosphere for continuous application. For example, bright annealing of stainless steel tubes. <br> <br>Features of Induction Heating Machines <br>High precision heating is essential for key applications such as automotive, aerospace, fiber optics, ammunition bonding, wire hardening, and spring wire tempering. Induction heating is very suitable for specialty metal applications involving titanium, precious metals and advanced composite materials. JKZ induction heating machines are widely used in mechanical forging heating processing, industrial heat treatment manufacturing, tool induction brazing manufacturing, food heating processing, and other fields. <br> <br>Advantages Of Induction Heating Machine <br> <br>Modular Design <br>According to the characteristics of the induction heater for industrial use, the modular design concept runs through JKZ&#039;s main circuit design and control circuit design, which greatly improves the application scope of our industrial induction heating machine and the convenience of its operation and maintenance. <br> <br>Main Core Components <br>JKZ Electronic adopts the latest IGBT from major international manufacturers as the core components of our induction heating equipment, which greatly improves the energy-saving efficiency of our induction heating generators.
