https://www.s2cinc.com/product....s/fpga-prototyping/l #SoC #validation Prodigy S7 Series (xilinx virtex ultrascale+ fpga) All versions of the Prodigy S7 Logic Systems can be used standalone or over multiple systems. The Prodigy Logic System are supported by the industry's broadest set of advanced FPGA solutions in S2C's Prodigy Complete Prototyping Solutions including:
Prodigy ProtoBridgeâ„¢ for linking FPGA prototyping to system-level simulations
Prodigy Multi-Debug Module for multi-FPGA deep trace debug
A vast library of 90+ daughter cards to meet a variety of interface needs
The available systems in Prodigy S7 Logic System series are: S7-9P, S7-13P, S7-19PS, S7-19PD and S7-19PQ
S2C offers complete FPGA prototyping solutions for ASIC/SoC validation & verification, helping engineers to accelerate software development, hardware verification, and system validation.
If you want to know more about fpga emulation, please visit our website.
https://www.s2cinc.com/product....s/fpga-prototyping/l #ip #verification Stratix 10 GX 10M With its latest intel fpga stratix 10 technology, the S2C Prodigy Intel Stratix 10 GX 10M FPGA module is compatible with 90+ Prodigy daughter card libraries, with a maximum capacity of up to 318 M ASIC gates in one FPGA. S2C's Stratix 10M Prodigy Logic System enables users to take advantage of the performance and functionality of Intel Stratix 10 FPGAs to meet their design needs by providing a complete design environment that includes all necessary fpga hardware and software.
FPGA Resources - Stratix 10 GX 10M
Large capacity and scalability with 40.8M Logic Elements
Up to1,102Mb memory
Up to13,842 DSP blocks
Technical Highlights
Up to 4,608 high-performance I/Os for inter FPGA connections and daughter cards
160 high-speed transceivers that can run up to 16Gbps
64 high-speed transceivers and 128 GPIOs through 8 PGT Connectors
S2C offers complete FPGA prototyping solutions for ASIC/SoC validation & verification, helping engineers to accelerate software development, hardware ip verification, and system validation.
https://www.s2cinc.com/product....s/fpga-prototyping/l #ip #validation Arria 10 S2C's Altera Arria 10 Prodigy Logic System, built on the Intel Arria 10 GX 1150, is an affordable solution for a variety of design sizes and applications. The Single A10 Prodigy Logic System is perfect for both prototyping small- to medium-sized SoCs and high-performance computing applications.
FPGA Resources - Intel Arria FPGA 10 GX1150
Large capacity with 1150K Logic Elements
Large scalability 53Mb of M20K memory
Supports 1,518 DSP blocks
Technical Highlights
44 Gb transceivers that can run up to 16Gbps
Offers up to 9.8M ASIC gates capacity
576 high-performance I/Os through 4 Prodigy connectors
If you want to know more about prototyping hardware, please visit our website.
S2C offers complete FPGA prototyping solutions for ASIC/SoC ip validation & verification, helping engineers to accelerate software development, hardware verification, and system validation.
https://www.s2cinc.com/product....s/fpga-prototyping/l #ku115 #fpga Prodigy Logic Module S2C's FPGA Prototyping system has been in the market since 2004 and has since been widely adopted by many leading SoC/ASIC design companies. The Prodigy Logic Module series are specially designed with low profile and affordability in mind. The Prodigy Logic Modules are based on Xilinx's VU, KU and K7 FPGA devices such as xilinx vu13p.
S2C Prodigy Logic Module Solution
Largest Capacity in Single FPGA
5,541 Logic Cells
2,880 DSP Slices
88.6Mb Internal memories
High System Performance
Up to two speed-grade improvement with high utilization comparing with V7-2000T
On-board support high speed DDR4 & PCIe Gen 3
Accelerated Design Productivity
Co-optimized with Vivado Design Suite for rapid design closure
Learn more about Prodigy Logic Module S2C Expands Kintex UltraScale Prototyping Solutions for Consumer-based IoT and Other Small to Medium-Sized Designs Low cost parallel system integration and software development.
S2C Prodigy FPGA Prototyping Logic Module Addresses Designs with Massive Parallel DSP Algorithms Prodigy KU is well suited for calculation-intensive applications with the most DSP resources of any other board on the market. The prototyping board also boasts 48 GTH transceivers for high-speed communication throughput. This low cost, all-purpose, stand-alone prototyping system is integrated with S2C's market-leading, vast library of prototyping daughter card to quickly build prototype targets.
If you want to know more about ku115 fpga, please visit our website.
Explore more functional verification methodologies for accelerating chip design at various design stages for various applications.
S2C offers FPGA prototyping solutions for SoC ASIC design and verification, IP/RTL verification and validation to reduce TTM in highly competitive markets
https://www.s2cinc.com/product....s/fpga-prototyping/d #SoC #verification Prototype Ready IP S2C offers the largest library of off-the-shelf interfaces and accessories for FPGA prototyping, referred to as Prototype Ready IP, also known as daughter boards. These fpga daughter boards are ready-to-use interfaces and accessories that seamlessly integrate with Prodigy Logic Modules, the Prodigy Logic System, and the Prodigy Logic Matrix, simplifying and accelerating the system prototyping process. S2C's accessory modules are available as prototyping daughter cards that can be easily plugged into the Prodigy family. These daughter boards have pre-tested interfaces and reference design flows, making system prototyping effortless. To obtain the latest reference design, please feel free to contact your S2C sales representative.
S2C Accessory Modules High Speed GT Peripherals​ PCIe Gen, PGT Module, PGT I/O connector, MCIO Module, Module Type B, QSFP+ connctors, QSFP + PGT Module, SFP+PGT Module, SATA PGT Module, SerDes, SMA PGT Module, Mini-SAS Module
High Speed MCIO Peripherals 8-Lane PCIe Root Complex MCIO ModuleProvides one x16 PCIe Slot, only support 8 lanesProvides one 100MHz reference clockProvides 3 LEDs and 1 Push ButtonsOccupies two MCIO connectorsMCIO to PGT Convert...
Connector Connectivity Prodigy Interconnection Module Type CConnects 144 GPIO and 4 SerDes between two Prodigy I/O connectors.The spacing between two connectors is 75mm.Available TypesReference ClockP-PM-IMCFixed 100MHzP-PM...
Learn more about Prototype Ready IP What's the importance of daughter cards in FPGA prototyping? A vast library of pre-tested FPGA daughter cards can save precious engineering time and reduce risks. S2C has dozens of prototyping daughter cards covering processors, embedded & multimedia, high-speed GT and memory applications.
What are the considerations for choosing daughter cards or the FPGA prototyping systems that will hold the daughter cards? FPGA prototyping system you select should have abundant unused I/O pins on I/O connectors to use daughter cards. The number of expansion connectors and types are important criteria when selecting suitable prototyping hardware. Another key consideration is whether the FPGA prototyping vendor can provide FPGA daughter boards customization services. Off-the-shelf solutions solve many problems but sometimes special system interfaces or optimizations for specific SoC and ASIC applications are required.
What's the problem of daughter card? A common problem is the limitations of current FPGA vendor's evaluation kits and in-house FPGA boards. Most evaluation boards have fixed interfaces embedded on the board which often cannot meet the SoC/ASIC prototyping requirements and is hard to reuse on new projects. Many home-grown FPGA boards also have the same limitation and easily get outdated when the design specification changes, and they are hard to reuse for future projects. S2C's Prototype Ready IP includes daughter cards and reference design. It makes daughter cards a very important part of the solution. The goal is to speed up and simplify customers’ system prototyping process.
What's the advantages of S2C's daughter cards? S2C has had numerous customization services over the past 15 years, the typical SOW covers schematic design, PCB layout, SI simulation (optional), manufacture, hardware initial bring-up and test design develop and delivery. Even if you would prefer to build the daughter card in-house S2C can provide the daughter card design guideline and support to speed your efforts and reduce risk of delays.
S2C is a leading global supplier of FPGA prototyping solutions for today's innovative SoC and ASIC designs, now with the second largest share of the global prototyping market. S2C has been successfully delivering rapid SoC prototyping solutions since 2003. With over 600 customers, including 11 of the world's top 25 semiconductor companies, our world-class engineering team and customer-centric sales team are experts at addressing our customer's ASIC and SoC verification needs. S2C has offices and sales representatives in the US, Europe, mainland China, Hong Kong, Korea and Japan.
